- Number of input points: 16
- Insulation method: Optocoupler insulation is used between the input terminals of all modules and the PC power supply.
- Rated input voltage: 24V DC
- Operating voltage range (V): 20.4 – 28.8
- maximum. Simultaneous opening (rated voltage): 100% (sink type)
- Rated input current (mA): approx. 4
- Common terminal arrangement: 16
- Power Indicator: Status LED for each input/output
- Connection terminal: 18-point detachable terminal block with screws
- Number of occupied I/O points: 16
- Internal power consumption (5V DC) (mA): 50 (all input points ON)”
- Dimensions?(L x W x H)??9cm x 2.74cm x 9.8cm
- Weight :0.16kg
- Country of Origin: ?Japan
