| Built-in depth | 69.5 mm |
| Degree of protection (IP), front side | IP66 |
| Height of the front | 252 mm |
| Number of colours of the display | 1670000 |
| Number of HW-interfaces industrial Ethernet | 1 |
| Number of HW-interfaces other | 0 |
| Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces PROFINET | 0 |
| Number of HW-interfaces RS-232 | 0 |
| Number of HW-interfaces RS-422 | 0 |
| Number of HW-interfaces RS-485 | 0 |
| Number of HW-interfaces serial TTY | 0 |
| Number of HW-interfaces USB | 1 |
| Number of HW-interfaces Wireless | 0 |
| Operation temperature | 0…55 ??C |
| Rail mounting possible | no |
| Screen size diagonal | 10 inch |
| Supply voltage DC | 24…24 V |
| Supporting protocol for EtherNet/IP | yes |
| Type of display | TFT |
| Voltage type of supply voltage | DC |
| Wall mounting/direct mounting | yes |
| Width of the front | 297 mm |
| With colour display | yes |
| With numeric keyboard | no |
| With SW interfaces | yes |
