| Width | 45.7 cm |
|---|---|
| Height | 144.8 cm |
| Depth | 115 cm |
| Torque, functional ground lug screw | 0.51 Nm |
| Torque, power terminal screw | 0.19 Nm |
Electrical
| Number of ports 10/100 Mbps RJ45 | 8 |
|---|---|
| Layer 2 | No |
| Layer 3 | No |
| Manageable | Yes |
| Pulse (digital) output | 5.3 W |
| Power dissipation | 5.3 W |
| Power Input | 12 – 24V DC, 0.4 – 0.2 A (SELV) |
| Total number of ports | 8 |
| Wire size, ethernet connection | RJ45 connector according to IEC 60603-7, 2 or 4-pair category 5e minimum cable according to TIA 568-B.1 or category 5 cable according to ISO/IEC 24702 |
| Ethernet | Yes |
| Wire size, DC power connection, solid or stranded copper wire rated at 30 ??C, or greater, above the surrounding air temperature | 0.82 mm2 |
| Wire size, ground connection, solid or stranded copper wire | 3.3 mm2 |
| Wiring category on communication ports | 2 |
| Wiring category on power ports | 2 |
